Type
36 x 24 mm CMOS
Effective Pixels
Approx. 30.3
megapixels
Total Pixels
Approx. 31.7
megapixels
Aspect Ratio
3:2
Low-Pass Filter
Built-in/Fixed
Sensor Cleaning
EOS integrated
cleaning system
Color Filter Type
Primary Color
Type
DIGIC 8
Lens Mount
RF (EF and EF-S
lenses can be attached using Mount Adapter EF-EOS R, Control Ring Mount Adapter
EF-EOS R, Drop-In Filter Mount Adapter EF-EOS R. EF-M lenses not compatible)
Focal Length
Equivalent to 1.0x
the focal length of the lens with RF and EF lenses 1.6x with EF-S
Type
Phase-difference
detection system with image sensor (Dual Pixel CMOS AF)
AF System/Points
With Area 88%
horizontal and 100% vertical
AF working range
EV -6 - 18 (at 23
Degree C & ISO100)
AF Modes
One Shot
Servo AF
AF Point Selection
Automatic
selection: Face + tracking
Manual selection: 1-point AF (AF frame size can be changed)
Manual selection: AF point Expansion 4 points (up, down, left, right)
Manual selection: AF point Expansion surrounding
Manual selection: Zone AF (all AF points divided into 9 focusing zones)
Manual selection: Large Zone AF (Vertical)
Manual selection: Large Zone AF (Horizontal)
AF Lock
Locked when shutter
button is pressed halfway or AF ON is pressed in One Shot AF mode. Using
customised button set to AF stop in AI servo
AF Assist Beam
Emitted by built in
LED or optional dedicated Speedlite (flash)
Manual Focus
Selected on lens
Metering modes
Real-time with
image sensor, 384-zone metering.
(1) Evaluative metering (linked to All AF points)
(2) Partial metering (approx. 6.1% of viewfinder at centre)
(3) Spot metering: Centre spot metering (approx. 2.7% viewfinder at centre)
AF point-linked spot metering not provided
(4) Centre weighted average metering
Metering Brightness Range
EV -3 - 20 (at 23
Degree C, ISO100, with evaluative metering)
AE Lock
Auto: AE lock takes
effect when focus is achieved
Manual: By AE lock button in P, Av, Fv, Tv and M
modes
Exposure Compensation
+/-3 EV in 1/3 or
1/2 stop increments (can be combined with AEB)
AEB
+/-3 EV in 1/3 or
1/2 stop increments
Anti-flicker shooting
Yes. Flicker
detected at a frequency of 100 Hz or 120 Hz. Maximum continuous shooting speed
may decrease
ISO Sensitivity
Auto 100-40000 (in
1/3-stop or whole stop increments)
ISO can be expanded to L:50, H1: 51200, H2: 102400
Type
Electronically-controlled focal-plane shutter and silent CMOS sensor readout
Speed
30-1/8000 sec (1/2
or 1/3 stop increments), Bulb (Total shutter speed range. Available range
varies by shooting mode)
Shutter Release
Soft touch
electromagnetic release
Type
Auto white balance
with the imaging sensor
Settings
AWB (Ambience
priority/White priority), Daylight, Shade, Cloudy, Tungsten light, White
Fluorescent light, Flash, Custom, Color Temperature
Setting
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/Green +/-9
Custom White Balance
Yes, 1 setting can
be registered
WB Bracketing
+/-3 levels in
single level increments
3, 2, 5 or 7 bracketed images per shutter release
Selectable Blue/Amber bias or Magenta/Green bias
Type
0.5-inch OLED color EVF
Dot count
3.69 Million dots (1280x960)
Coverage (Vertical/Horizontal)
Approx. 100%
Magnification
Approx. 0.76x 1
Eyepoint
Approx. 23mm (from
eyepiece lens centre)
Dioptre Correction
-4 to +2 m-1
(dioptre)
Viewfinder Information
AF point
information, Exposure level indicator, Number of remaining multiple exposures,
Exposure compensation, HDR shooting, Highlight tone
priority, Multiple-exposure shooting, ISO speed, Dual Pixel RAW shooting,
Possible shots, Multi Shot Noise Reduction, Number of self-timer shooting,
Digital Lens Optimizer, Maximum burst, AF method, Battery level, AF operation,
Exposure simulation, Drive mode, AEB, Metering mode
Viewfinder Information (Contd.)
FEB, Anti-flicker
shooting, Still photo cropping, Shooting mode, Aspect
ratio, Scene icons, Auto Lighting Optimizer, AE lock Picture Style,
Flash-ready, White balance, Flash off, White balance correction, FE lock, Image
Quality, High-speed sync, Bluetooth function, Shutter speed, Wi-Fi function,
Multi-function lock warning, Histogram, Aperture, Electronic level, Lens
information
Eyepiece shutter
N/A
Type
8.01cm (3.15")
Clear View LCD II, approx. 2.1million dots
Coverage
Approx. 100%
Viewing Angle
Approx. 170 Degree
vertically and horizontally (horizontally/vertically)
Coating
Anti-smudge.
Reinforced glass incorporated
Brightness Adjustment
Manual: Adjustable
to one of seven levels
Color Tone Adjustment: 4 settings
Touch-screen operations
Capacitive method
with menu functions, Quick Control settings, playback operations, and magnified
display. AF point selection in still and Movies, touch shutter is possible in
still photo shooting.
Display Options
(1) Basic Camera
settings
(2) Advance Camera settings
(3) Camera settings plus histogram and dual level display
(4) No info
(5) Quick Control Screen
Modes
E-TTL II Auto
Flash, Metered Manual
X-sync
1/200sec
Flash Exposure Compensation
+/- 3EV in 1/3
increments with EX series Speedlite flashes
Flash Exposure Bracketing
Yes, with
compatible External Flash
Flash Exposure Lock
Yes
Second Curtain Synchronisation
Yes via Speedlite
HotShoe / PC terminal
Yes/Yes via Battery
Grip BG-E22
External Flash Compatibility
E-TTL II with EX
series Speedlite, wireless multi-flash support
External Flash Control
via camera menu
screen
Modes
Stills; Scene
Intelligent Auto, Flexible priority AE, Program AE, Shutter priority AE,
Aperture priority AE, Manual, Bulb and Custom (x3)
Movie: Scene Intelligent Auto, Program AE, Shutter priority AE, Aperture
priority AE, Manual, Bulb and Custom (x3)
Picture Styles
Auto, Standard,
Portrait, Landscape, Fine Detail, Neutral, Faithful, Monochrome, User Defined
(x3)
Color Space
sRGB and Adobe RGB
Image Processing
Highlight Tone
Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings) (still and video)
Lens optical correction:
Peripheral illumination correction, Chromatic aberration correction, Distortion
correction (during/after still photo shooting, during video only)
Diffraction correction, Digital Lens Optimizer (during/after still photo
shooting)
Image Processing (Contd.)
Resize to M, S1, S2
Cropping: JPEG images can be cropped (Aspect ratios 3:2, 4:3, 16:9, 1:1)
45 cropping sizes selectable, from 11% to 95% (diagonal)
Switch between vertical and horizontal cropping orientation
Image straightening
Cropping frame can be moved using touch screen operation
RAW image processing
Multiple exposure
HDR
Drive modes
Single, Continuous
High, Continuous Low, Silent Single, Self timer
(2s+remote, 10s+remote)
Continuous Shooting
Max. Approx. 8fps.
speed maintained for 100 JPEG, 47 RAW, 78 C-RAW images456
Max. 5fps with AF Tracking
Interval timer
4k time lapse movie
Type
Electronic
viewfinder with image sensor
Coverage
Approx. 100%
(horizontally and vertically)
Frame Rate
59.97 fps (smooth)
/ 29.97 fps (power saving)
Focusing
Manual Focus
(Magnify the image 5x or 10x at any point on screen)
Autofocus: Dual Pixel CMOS AF (Face Detection and Tracking AF, 1point AF,
Expand AF Area Zone AF, and Touch shutter
Metering
Real-time
evaluative metering with image sensor (384-zone)
Partial metering (approx. 6.1% of the centre of the screen)
Spot metering (approx. 2.7% of the centre of the screen)
Centre-weighted average metering
Active metering timer can be changed
Display Options
3 levels available
Basic shooting information, Advanced shooting information and Advanced shooting
information with Histogram
Still Image Type
JPEG: 2 compression
options
RAW: RAW, C-RAW and Dual Pixel RAW (14-bit, Canon original RAW 3rd edition)
Complies with Exif 2.31 and Design rule for Camera File system 2.0
Complies with Digital Print Order Format [DPOF] Version 1.1
RAW+JPEG recording
Yes, any
combination of RAW + JPEG possible, including Dual Pixel RAW +JPEG
(simultaneous)
Image Size
JPEG:
3:2 ratio (L, RAW, C-RAW) 6720x4480, (M1) 4464x2976, (S1) 3360x2240, (S2)
1696x1280
1.6x (crop) (L) 4176x2784, (S2) 2400x1600
4:3 ratio (L) 5952x4480, (M1) 3968x2976, (S1) 2976x2240, (S2) 2112x1600
16:9 ratio (L) 6720x3776, (M1) 4464x2512, (S1) 3360x1888, (S2) 2400x1344
1:1 ratio (L) 4480x4480, (M1) 2976x2976, (S1) 2240x2240, (S2) 1600x1600
Folders
New folders can be
manually created and selected
File Numbering
(1) Consecutive
numbering
(2) Auto reset
(3) Manual reset
Movie Type
MP4 Video: 4K
(16:9) 3840 x 2160, Full HD, HD
MPEG4 AVC/H.264 variable (average) bit rate, Audio: Linear PCM
Movie Size
4K (16:9) 3840 x
2160 (29.97, 25, 24, 23.98 fps) intra or inter frame7
Full HD (16:9) 1920 x 1080 (59.94, 50, 29.97, 25, 23.98 fps) intra or inter
frame
Full HD (16:9) 1920 x 1080 HDR (29.97, 25 fps) inter frame
Full HD (16:9) 1920 x 1080 (29.97, 25) light inter frame
HD (16:9) 1280 x 720 (119.9, 100 fps) intra frame
Color Sampling
4K - YCbCr4:2:0
(8-bit)
Full HD/HD - YCbCr4:2:0 (8-bit) (Internal recording)
Canon Log
Yes Log 1
Movie Length
4K and Full HD -
Max duration 29min 59sec. (excluding High Frame Rate movies). No 4GB file limit
with exFAT SDXC
High Frame Rate Movie
MOV Video: HD -
1280 x 720 at 100fps or 119.9fps
Recorded as 1/4-speed slow motion movie
Single scene maximum recording up to 7min 29sec.
4K Frame Grab
8.3-megapixel JPEG
still image frame grab from 4K movie possible
Bitrate / Mbps
4K
(29.97p/25.00p/24.00p/23.98p): ALL-I Approx. 480 Mbps
4K (29.97p/25.00p/24.00p/23.98p): IPB Approx. 120 Mbps
Full HD (59.94p/50.00p): ALL-I Approx. 180 Mbps
Full HD (59.94p/50.00p): IPB Approx. 60 Mbps
Full HD (29.97p/25.00p/24.00p/23.98p): ALL-I Approx. 90 Mbps
Full HD (29.97p/25.00p/24.00p/23.98p): IPB Approx. 30 Mbps
Bitrate / Mbps (Contd.)
Full HD
(29.97p/25.00p): IPB (Light) Approx. 12 Mbps
HD (119.9p/100.0p): ALL-I Approx. 160 Mbps
HD (59.94p/50.00p): ALL-I Approx 80 Mbps
HD (59.94p/50.00p): IPB Approx 26 Mbps
HD (29.97p/25.00p): IPB Approx 13 Mbps
Microphone
Built-in stereo
microphones (48 Khz, 16-bit x 2 channels)
HDMI Display
External Monitor
only, External Monitor only without information display or Simultaneous on
camera and external monitor
HDMI Output
4K (UHD)
uncompressed YCbCr 4:2:2, 8-bit or 10-bit, Full HD
1080P YCbCr 4:2:2, 8-bit. Supported outputs 4K
UHD/29.97P, 4K UHD/25.00P, 4K UHD/24.00P, 4K UHD/23.98P, 1080/59.94P
1080/50.00P, 1080i/50.00i, 1080i/59.94i, 1080/24.00P, 576p/50.00P, 480/59.94p.
Sound output via HDMI is also possible
Focusing
Dual Pixel CMOS AF
with Face Detection and Tracking AF, Movie Servo AF Manual Focus
ISO
4K - Auto:
100-12800, H: 25600, H: 32000, H1: 51200, H2: 102400,
Full HD/HD - Auto: 100-25600, H: 32000, H1: 51200, H2:102400
Custom Functions
22 Custom Functions
Metadata Tag
User copyright
information (can be set in camera)
Image rating (0-5 stars)
IPTC data (registered with EOS Utility)
Image transfer with caption (Caption registered with EOS Utility)
LCD Panel / Illumination
Yes/Yes
Water/Dust resistance
Yes
Voice Memo
No
Intelligent Orientation Sensor
Yes
Playback zoom
1.5x - 10x in 15
steps
Display Formats
(1) Single image
(2) Single image with information (2 levels)
Basic - Shooting information (shutter speed, aperture, ISO
and Image quality)
Detailed - Shooting information (shutter speed, aperture, ISO, metering Image,
quality and file size), Lens information, Brightness and RGB histogram, White
balance, Picture Style, Color space and noise
reduction, Lens optical correction, GPS information, IPTC information
Display Formats (Contd.)
(3) 4 image index
(4) 9 image index
(5) 36 image index
(6) 100 image index
(7) Jump Display (1, 10 or 100 images, Date, Folder, Movies, Stills, Protected
images, Rating)
(8) Movie edit
(9) RAW processing
(10) Rating
Slide Show
Image selection:
All images, by Date, by Folder, Movies, Stills, Protected images or Rating
Playback time: 1/2/3/5/10 or 20 seconds
Repeat: On/Off
Histogram
Brightness: Yes
RGB: Yes
Highlight Alert
Yes
Image Erase
Single image,
select range, Selected images, Folder, Card
Image Erase Protection
Erase protection of
Single image, Folder or Card all found images (only during image search)
Self Timer
2 or 10 sec.
Menu Categories
(1) Shooting menu
(2) AF Menu
(3) Playback menu
(4) Setup menu
(5) Custom Functions menu
(6) My Menu
Menu Languages
29 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian,
Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian,
Vietnamese, Hindi, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified
Chinese, Traditional Chinese, Korean, Malay, Indonesia
and Japanese
Firmware Update
Update possible by the user (Camera, Lens, WFT, External Speedlite, BLE remote control, Lens adapter)
Computer
SuperSpeed USB 3.1
USB C connector
Wi-Fi
Wireless LAN
(IEEE802.11b/g/n) (2.4 GHz only), with Bluetooth support8 Features supported -
EOS Utility, Smartphone, Upload to Web, Wireless printing
Other
HDMI mini out (Type
C, HDMI-CEC compatible), External Microphone In/Line In (Stereo mini jack),
Headphone socket (Stereo mini jack), E3-type terminal (remote control terminal)
PictBridge
Yes (Via Wireless
LAN only)
Type
1x SD/SDHC/SDXC and
UHS-II
PC & Macintosh
Windows 7 (excl.
Starter Edition) Windows 8.1 and Windows 10 (tablet mode not supported)
OS X v10.11-10.14
Image Processing
Digital Photo
Professional 4.9 or later (RAW Image Processing)
Other
EOS Utility 3.9 or
later (incl. Remote Capture), Picture Style Editor, Map Utility, EOS Lens
Registration Tool, EOS Web Service Registration Tool, Canon Camera connect app
(iOS/Android)
Batteries
Rechargeable Li-ion
Battery LP-E6N (supplied)/LP-E6
Battery life
Approx. 370 shots
(at 23 Degree C)9
Approx. 350 (at 0 Degree C)
Battery Indicator
6 levels +
percentage
Power saving
Power turns off
after 30 seconds, 1, 3, 5, 10 or 30mins
Power Supply & Battery Chargers
Battery charger
LC-E6E (supplied), AC Adapter AC-E6N and DC Coupler DR-E6, AC Adapter Kit
ACK-E6N/ACK-E6, Car Battery Charger CBC-E6, USB Power Adapter PD-E1
Wireless File Transmitter
Wireless File
Transmitter WFT-E7B
Lenses
All RF lenses (EF
& EF-S via Lens adapters)
Lens adapters
Mount Adapter
EF-EOS R, Control Ring Mount Adapter EF-EOS R, Drop-In Filter Mount Adapter
EF-EOS R
Flash
Canon Speedlite (EL-100, 90EX, 220EX, 270EX, 270EX II, 320EX,
380EX, 420EX, 430EX, 430EX II, 430EX III 470EX-AI, 550EX, 580EX, 580EX II,
600EX, 600EX-RT, 600EX-II-RT, Macro-Ring-Lite MR-14EX, Macro Ring Lite MR-14EX
II, Macro Twin Lite MT-24EX, Macro Twin Lite MT-26EX Speedlite
Transmitter ST-E2, Speedlite Transmitter ST-E3-RT)
Remote Controller / Switch
Remote control with
E3 type socket and Speedlite 600EX-II-RT
Other
Battery Grip
BG-E22, GP-E2 GPS receiver
Body Materials
Magnesium Alloy
body and polycarbonate with glass Fiber parts
Operating Environment
32 - 104 Degree F
(0 - 40 Degree C), 85% or less humidity
Dimensions (W x H x D)
5.34 x 3.87 x
3.32" (135.8 x 98.3 x 84.4mm)
Weight
20.45 oz (580g)
(660 g with card and battery) (body only)
