Image Sensor Type
1/2.3 type
back-illuminated CMOS
Effective Pixels
Approx. 20.3M1
Total Pixels
Approx. 21.1M
Color Filter Type
Primary Color
Image Processor Type
DIGIC 8
Focal Length
3.8 - 247.0 mm (35
mm equivalent: 21 - 1365 mm)
Zoom
Optical 65x
ZoomPlus 130x
Digital approx. 4.0x (with Digital Tele-Converter Approx. 1.6x or 2.0x)
Combined approx. 260x
Maximum f/number
f/3.4 - f/6.5
Construction
15 elements in 11
groups (3 UD lenses, 1 double-sided aspherical lens)
Image Stabilization
Yes (lens
shift-type), Approx. 5 stop. Intelligent IS with Dual
Sensing IS plus 5-axis Advanced Dynamic IS
Focusing Type
TTL
AF System/ Points
Face & Tracking
(9 points), Tracking, 1-point, Spot
AF Modes
One Shot, Servo,
Continuous
AF Assist Beam
Yes
Manual Focus
Yes, plus MF
Peaking
Closest Focusing Distance
0cm (W) from front
of lens in Macro
Metering modes
Evaluative,
Centre-weighted average, Spot (except movie)
AE Lock
Yes
Exposure Compensation
+/- 3 EV in 1/3
stop increments
ISO Sensitivity
100-3200 in 1/3
stop increments
Speed
15 - 1/2000 s
Settings
Auto , Daylight, Shade, Cloudy, Tungsten, Fluorescent, Flash, Custom
Viewfinder
0.39 type, approx.
2.36m dots
Viewfinder / Coverage
Approx. 100%
Diopter Correction
Approx. -3.0 - +1.0
m-1 (dpt)
Monitor
7.5 cm (3.0") Vari-Angle LCD (TFT), approx. 922,000 dots
Coverage
Approx. 100%
Brightness
Adjustable to one
of five levels
Modes
Auto, Manual Flash
On / Off, Slow Synchro
X-Sync Speed
Fastest speed
1/2000 s
Red-Eye Correction
Yes
Flash Exposure Compensation
+/- 2 EV in 1/3
stop increments
Flash Exposure Lock
Yes
Manual Power Adjustment
3 levels with
internal flash
Second Curtain Synchronization
Yes
Built-in Flash Range
Approx. 48cm - 6.5m
(W) / 1.8m - 4m (T)
Modes
Smart Auto (29
scenes detected), Hybrid Auto, Creative Shot, Program AE, Shutter priority AE,
Aperture priority AE, Manual, Sports, SCN
Drive modes
Single, High-speed
continuous, low-speed continuous
Continuous Shooting
Max: One Shot AF
approx. 10fps, Servo AF approx. 7.4fps
Recording Pixels /
Compression
Image Size
4:3 - (L) 5184 x
3888, (M) 3648 x 2736, (S) 2432 x 1824
16:9 - (L) 5184 x 2912, (M) 3648 x 2048, (S) 2432 x 1368
3:2 - (L) 5184 x 3456, (M) 3648 x 2432, (S) 2432 x 1616
1:1 - (L) 3888 x 3888, (M) 2736 x 2736, (S) 1824 x 1824
Compression
Fine, Normal
Movies
(4K) 3840 x 2160,
29.97/25 fps (Full HD) 1920 x 1080, 59.94/50/29.97/25 fps, (HD) 1280 x 720,
59.94/50 fps
Movie Length
Up to 29 min 59 s
Still Image Type
JPEG compression,
(Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system 2.0,
Digital Print Order Format [DPOF] Version 1.1 compliant
Movies
MP4 [Video: MPEG-4
AVC / H.264, Audio: MPEG-4 AAC-LC (stereo)]
Canon Printers
Canon Compact Photo
Printers SELPHY and Canon Inkjet Printers supporting PictBridge
PictBridge
Yes (via USB or
Wireless LAN)
GPS
GPS via Mobile (via Canon Camera Connect app with
compatible smart devices)
Red-Eye Correction
Yes, during
shooting and playback
Histogram
Yes, during
playback
Playback zoom
Approx. 2x - 10x
Self Timer
Approx. 2, 10 s or
Custom
Menu Languages
English, German,
French, Dutch, Danish, Finnish, Italian, Greek, Norwegian, Portuguese, Russian,
Swedish, Spanish, Ukrainian, Polish, Czech, Hungarian, Turkish, Simplified
Chinese, Chinese (traditional), Japanese, Korean, Thai, Arabic, Romanian,
Farsi, Hindi, Malay, Indonesian, Vietnamese, Hebrew
Computer
Hi-Speed USB
dedicated connector (Micro-B compatible)
Other
HDMI Micro (Type-D)
Connector
Computer/Other
Wi-Fi
(IEEE802.11b/g/n), (2.4 GHz only)
Memory Card Type
SD, SDHC, SDXC
(UHS-1 Speed Class 3 compatible)
Supported Operating
System
PC & Macintosh
Windows 10 / 8.1 /
8 / 7 SP1
Mac OS X 10.9 / 10.10 / 10.11
For Wi-Fi connection to a PC:
Windows 10 / 8.1 / 8 / 7 SP1
Mac OS X 10.9 / 10.10
For Image Transfer Utility:
Windows 10 / 8.1 / 8 / 7 SP1
Mac OS X 10.9 / 10.10 / 10.11
Other
Image Transfer
Utility
Camera Connect app available on iOS and Android devices
Batteries
Rechargeable Li-ion
Battery LC-E12 (battery and charger supplied)
Battery life
Approx. 325 shots
Eco Mode: Approx. 405 shots
Playback Mode: Approx. 360 min
Operating Temperature
0 to 40 deg. C (32
to 104 deg. F)
Humility
10-90%
Dimensions
127 x 90.9 x
116.6mm (5.00 x 3.58 x 4.59")
Weight
Approx. 610g (21.52
oz) (including battery and memory card)
