Canon RF 800mm f/5.6 L IS USM Lens
Canon RF 800mm f/5.6 L IS USM Lens
Canon RF 800mm f/5.6 L IS USM Lens
Canon RF 800mm f/5.6 L IS USM Lens
Canon RF 800mm f/5.6 L IS USM Lens
  • SKU: 5055C002
  • Availability: In stock Available in stock Out of stock New Item - Coming Soon

Canon RF 800mm f/5.6 L IS USM Lens

₹1,520,390 ₹1,599,995
Inclusive of all taxes.

Canon RF 800mm f/5.6L IS USM Overview

Powerful Reach, Unprecedented Portability

Relatively sleek despite its super-telephoto reach, the Canon RF 800mm f/5.6 L IS USM is an impressive prime meshing top-of-the-line performance with an updated compact and lightweight design. Ideal for sports, wildlife, and journalism applications, this long lens offers a distinctly tight field of view for isolating distant subjects, along with responsive AF and image stabilization, reliable weather-sealing, and intuitive handling for dependable use in fast-paced situations.

L Series Optics

  • Featuring an optical design based on past EF and RF super-telephoto lenses, this lens features top-range optics designed for the most demanding shooting applications.
  • Two fluorite, one Super Ultra Low-Dispersion (UD), and one UD element virtually eliminate chromatic aberrations for outstanding clarity and color accuracy, void of chromatic aberrations or fringing.
  • Advanced optical design also contributes to the sleeker, more portable form factor of this RF-mount, mirrorless lens.
  • Both Air Sphere and Super Spectra Coatings improve image quality by maintaining high contrast and color accuracy while reducing lens flare and ghosting when working in strong lighting conditions.
  • Rounded nine-blade diaphragm contributes to a smooth bokeh quality.

USM Autofocus and Image Stabilization

  • Ultrasonic Motor delivers fast, accurate, and near silent autofocus performance to benefit both photo and video applications.
  • Impressively close 8.5' minimum focusing distance, and a maximum magnification of 0.34x, suit working with nearby subjects, such as close-range wildlife, birds, and athletes.
  • Variable speed manual focusing offers three options for greater focusing control and full-time manual focus support permits making focus adjustments without switching modes.
  • Two focus presets can be stored for immediate recall to a specified focus distance.
  • Focus range limiter improves responsiveness by constraining the usable focusing range.
  • Benefitting handheld and monopod-based shooting, Optical Image Stabilization compensates for 4.5 stops of camera shake for sharper imagery. Due to the long focal length, in-body image stabilization, or Coordinated IS, from EOS R-series bodies is not supported with with this lens.

Intuitive Handling and Professional Reliability

  • Relatively lightweight and compact, this 800mm f/5.6 lens weighs 6.9 lb and measures 17"-long, making it realistic to use atop a monopod or even handheld for short periods of time.
  • Built-in rotating tripod mount suits working with the lens atop a monopod or tripod and enables quick switching between vertical and horizontal shooting orientations.
  • Weather-sealed design for reliable use in inclement conditions.
  • Fluorine coating on front element helps repel moisture, dust, and fingerprints and is also easier to clean.
  • Distinctive heat-resistant white paint finish.
  • Accepts drop-in style 52mm filters toward the rear of the lens.
  • Compatible with optional Extender RF 1.4x and 2x teleconverters for further extending the effective reach of this lens.


Focal Length
Maximum and Minimum Aperture
f/5.6 - f/64
Lens Mount Type
RF Mount, metal
Compatible Cameras
Canon EOS R-series
Minimum Focusing Distance
8.53' (2.6m)
Maximum Magnification
Field of View, at Minimum Focus Distance
Approx. 8.1 x 5.4" (206 x 138mm)
Angle of View (Diagonal)
03 Degree 05'

RF Extender Compatibility

Canon RF Extender 1.4x/2x
Equivalent Focal Length
RF1.4x - 1120mm f/8
Maximum Aperture
RF2x - 1600mm f/11
Max close-focusing magnification
RF1.4x - 0.49x
RF2x - 0.71x
Autofocus with EOS R-series cameras
Possible with either extender (as of 2/2022)
Image Stabilizer w/EOS R-series cameras
Possible with either extender (as of 2/2022)

Optical Design

Lens Construction
26 elements in 18 groups
Special Elements
(2) Fluorite, (1) Super UD Lenses, (1) UD (Ultra-low Dispersion)
Lens Coating
Super Spectra Coating, Fluorine Coating, ASC
Filter Size Diameter
Aperture Blades
9, circular shape
Image Stabilization
4 stops correction with In-lens Optical Image Stabilization


Focusing Drive System
Canon USM low-speed drive (Ring USM)
Full-time Manual Focusing
(Supports both ONE SHOT AF and SERVO AF with compatible EOS R-series cameras)
Manual Focus Speed Selection
Yes (1, 2, and 3 settings, via switch on lens)
1= fastest MF; 3= slowest MF rotation
Focus Distance Range Selection
Yes (3 positions, via switch on lens)
FULL - 8.5' (2.6m) - infinity
8.5' (2.6m) - 20m/65.6 feet
65.6' (20m) - infinity
Dual Pixel CMOS AF Coverage (HxV)
EOS R5/R6 - approx. 100% x 100%
EOS R - approx. 88% x 100%
With Extender RF1.4x
EOS R5/R6 - approx. 100% x 100%
EOS R - approx. 88% x 100%
With Extender RF2x
EOS R5/R6 - approx. 80% x 80%
EOS R - approx. 80% x 80%
Power Focus
Yes, via rotation of Playback Ring
Lens Focus Preset switch set to OFF; Focus Mode switch set to PF
Two focus speeds, based on ring rotation angle

Image Stabilization

IS On-Off
Image Stabilizer switch, on lens barrel
Optical Image Stabilization
4 stops correction (CIPA standard) with both EOS R and R5
IS Mode Selection
IS Modes 1, 2 and 3 (via switch on lens barrel)
Mode 1 - general shake correction
Mode 2 - correction during panning
Mode 3 - correction only during exposure
Panning Mode Support (SCN Mode)

Exterior Design

Control Ring
Dual-function Manual focus ring / Control Ring (selected using camera menu)
Manual Focus Ring
Electronic ring system
Full-time Manual focus possible
No physical limit to ring rotational angle
AF/MF Switch
Yes - AF/PF/MF Switch
MF/Control Ring Switch
None - must be selected in camera menu
Distance Scale
Distance scale available in EVF or Live View LCD screen of compatible EOS R-series cameras
Distance Limiter Switch
Full (2.6m to infinity) / 2.6m to 20m / 20m to infinity
Focus Pre-set Function
Yes, via Playback Ring on lens barrel
Off - On - On with beep tone, via lens switch
Distance memorized via Focus Preset button
Two distances can be memorized; immediate return to either via direction of Playback Ring
Lens Function Buttons
Yes; four positioned on lens barrel
(AF-Stop Buttons)
Dust / Weather Resistant Construction
Yes - rubber ring on lens mount


Approx. 6.4 x 17.0" (163 x 432mm)
Approx. 6.9 lbs (3.14kg)
  • RF-Mount Lens/Full-Frame Format

  • Aperture Range: f/5.6 to f/64

  • Fluorite, Super UD, and UD Elements

  • Air Sphere and Super Spectra Coatings

  • Ring-Type USM AF System

  • Optical Image Stabilizer

  • Focus Range Limiter, Two Focus Presets

  • Customizable Electronic Focus Ring

  • Weather-Sealed Design, Fluorine Coating

  • Rotating Tripod Collar

  • Canon RF 800mm f/5.6 L IS USM Lens
  • Canon Lens Cap E-180E
  • Canon Lens Dust Cap RF
  • Canon Lens Hood ET-155 (WIII)
  • Canon Drop-In Screw Filter Holder 52 (WIII) with Protect Filter
  • Canon Lens Soft Case LS600
  • Canon Wide Lens Strap B
  • Limited 1-Year Manufacturer Warranty
