Type
Digital single-lens
non-reflex AF/AE camera
Image Processor
DIGIC X
Recording Media
CFexpress card:
Type B: Card slot
SD card:
SD card speed class-compatible
Compatible with UHS-II
Eye-Fi cards and Multimedia cards (MMC) are not supported
Compatible Lenses
Canon RF lens group
(excluding EF, EF-S and EF-M lenses)
When using Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M
lenses)
Lens Mount
Canon RF mount
Type
CMOS sensor
(compatible with Dual Pixel CMOS AF)
Effective Pixels
Approx. 45.0
megapixels
Sensor Size
Approx. 36.0 x 24.0
mm
Pixel Size
Approx. 4.40 microm square
Total Pixels
Approx. 47.1
megapixels
Aspect Ratio
3:2 (Horizontal:
Vertical)
Color Filter System
RGB primary color filters
Low Pass Filter
Installed in front
of the image sensor, non-detachable
Dust Deletion Feature
Self Cleaning
Sensor Unit:
Removes dust adhering to the low-pass filter
At power off only / Enable / Disable. Performed automatically (taking about
approx. 2 sec. as indicated on the screen) or manually (taking about approx. 8
sec. as indicated on the screen)
After manually activated cleaning, the camera will automatically restart (Power
OFF to ON)
Dust Deletion Feature (Contd.)
When (Multi Shot
Noise Reduction), (Multiple exposures), or (HDR mode) is set, (Clean now) and
(Clean manually) cannot be selected
Dust Delete Data acquisition and appending:
The coordinates of the dust adhering to the low-pass filter are detected by a
test shot and appended to subsequent images
Dust Deletion Feature (Contd..)
The dust coordinate
data appended to the image is used by the EOS Canon Digital Professional
Software (v. 4.14 and higher) to automatically erase the dust spots
Not available with EF-S lenses, in cropped shooting or multi-exposure shooting
Manual cleaning (by hand)
Recording Format
Compliant to Design
rule for Camera File system 2.0 and Exif 2.3
Image Format
JPEG, HEIF, RAW
(CR3, 14 bit RAW format), C-RAW (Canon original);
Movies: ALL-I, IPB, RAW
HDR Mode Continuous Shooting
1 shot only
Continuously
Multiple Exposure
Advanced shooting operations
Focus Bracketing
Interval Timer
Bulb Timer
Multi-Shot NR
File Size
3:2 Aspect Ratio
Large/RAW/C-RAW: 8192 x 5464
Medium: 5808 x 3872
Small 1: 4176 x 2784
Small 2: 2400 x 1600
1.6x (Crop)
Large/RAW/C-RAW: 5088 x 3392
Small 2: 2400 x 1600
4:3 Aspect Ratio
Large: 7280 x 5464
Medium: 5152 x 3872
Small 1: 3712 x 2784
Small 2: 2112 x 1600
RAW/C-RAW: 8192 x 5464
File Size (Contd.)
16:9 Aspect Ratio
Large: 8192 x 4608
Medium: 5808 x 3264
Small 1: 4176 x 2344
Small 2: 2400 x 1344
RAW/C-RAW: 8192 x 5464
1:1 Aspect Ratio
Large: 5456 x 5456
Medium: 3872 x 3872
Small 1: 2784 x 2784
Small 2: 1600 x 1600
RAW/C-RAW: 8192 x 5464
File Size (Contd..)
Values for
Recording Pixels are rounded to the nearest 100,000 or 10,000
For RAW and JPEG images, information outside the cropping area is not retained
JPEG images are generated in the set aspect ratio
RAW images are generated in (3:2), and the set aspect ratio is appended
RAW + JPEG / HEIF
Simultaneous
recording of any combination of RAW/C-RAW and JPEG/HEIF image-recording quality
is supported
Color Space
Selectable between
sRGB and Adobe RGB
Picture Style
Auto
Standard
Portrait
Landscape
Fine Detail
Neutral
Faithful
Monochrome
User Defined 1-3
Settings
Auto (Ambience
priority/White priority)
Daylight
Shade
Cloudy
Tungsten light
White fluorescent light
Flash
Custom (Custom WB)
Color temperature
Auto White Balance
Option between
ambience priority and white priority settings.
White Balance Shift
Blue/amber bias:
+/-9 levels
Magenta/green bias: +/-9 levels
Corrected in reference to the current WB mode's color
temperature
Type
OLED color electronic viewfinder; approx. 5.76 million dots
resolution
Coverage
Approx. 100%
vertically and horizontally relative to the shooting image area (with image
quality L, at approx. 23mm eyepoint)
Magnification / Angle of View
Approx. 0.76x /
Approx. 35.5 degrees (with 50mm lens at infinity, -1 m-1)
Eye Point
Approx. 23mm (at -1
m-1 from the eyepiece lens end)
Dioptric Adjustment Range
Approx. -4.0 to +
2.0 m-1 (dpt)
Viewfinder Information
Maximum burst
Possible shots/Sec. until self-timer shoots
Focus Bracketing/ Multiple-exposure/HDR shooting/Multi
Shot Noise Reduction/Bulb time/Interval timer
Shooting mode
AF method
AF operation
Image quality
Card
Drive mode
Metering mode
No. of remaining shots for focus bracketing, multiple exposures, or interval
timer
Electronic level
Viewfinder Information (Contd.)
Movie recording
time available
Battery level
Image Stabilizer (IS mode)
Histogram (Brightness/RGB)
Quick Control button
Anti-flicker shooting
White balance/White balance correction
Picture style
Auto Lighting Optimizer
Still photo cropping / Aspect ratio
AF point (1-point AF)
AEB/FEB
View Assist
HDR PQ
Viewfinder Information (Contd..)
Flash ready / FE
lock / High-speed sync
Electronic shutter
Touch shutter / Create folder
AE lock
Shutter speed / Multi-function lock warning
Aperture value
Wi-Fi function
Wi-Fi signal strength
Bluetooth function
Exposure simulation
Magnify button
ISO speed
Highlight tone priority
Exposure compensation
Exposure level indicator
Focus Method
Dual Pixel CMOS AF
II
Number of AF zones available
AF area:
Horizontal: Approx. 100% x Vertical: Approx. 100%
Stills: Max. 1053 zones (39 x 27)
Movies: Max. 819 zones (39 x21)
(for Automatic Selection)
AF Working Range
EV -6 to 20 (f/1.2
lens, center AF point, One-Shot AF,at 73 Degree F/23 Degree C, ISO 100)
AF Methods
Face+Tracking AF
Spot AF
1-point AF
Expand AF Area (Above, below, left and right/Around)
Zone AF
Large Zone AF: Vertical, Horizontal
Subject to Detect
People, Animals, No
Priority
Metering Modes
Real-time metering
with image sensor (384 zones (24x16 zone metering))
(1) Evaluative metering (AF point-linked)
(2) Partial metering (approx. 6.1% of the area at the center
of the screen)
(3) Spot metering (approx. 3.1% of the area at the center
of the screen)
(4) Center-weighted average metering
Metering Range
EV -3 - 20 (at 73
Degree F/23 Degree C, ISO 100) (Still Photo Shooting)
Exposure Control Modes
Scene Intelligent
Auto
Flexible-priority AE (Fv)
Program AE (P)
Shutter-priority AE (Safety shift possible) (Tv)
Aperture-priority AE (Safety shift possible) (Av)
Manual exposure (M)
Bulb
Custom shooting mode C1, C2, C3
Exposure Compensation
Manual: +/-3 stops
in 1/3- or 1/2-stop increments
AEB: +/-3 stops in 1/3- or 1/2-stop increments
AE Lock
Auto AE lock:
The metering mode for AE lock after one-shot focus can be customized
User-applied AE lock:
In the Fv, P, Tv, Av and M modes, enabled with the AE
lock button. (Press again to update.)
Enabled in all metering modes
Type
Mechanical
Electronic 1st-Curtain
Electronic Shutter (1st and 2nd curtain - silent)
Shutter Speeds
When (Mechanical)
or (Elec. 1st- curtain) is set: 1/8000-30 sec, bulb
When (Electronic) is set: 1/8000-0.5 sec
X-sync Speed
Mechanical Shutter:
1/200 sec
Elec. 1st-curtain: 1/250 sec
Shutter Release
Soft-touch
electromagnetic release
Self Timer
10-sec. delay,
2-sec. delay
Image Stabilization
(IS mode)
Still Photo IS
Optical IS with RF
and EF lenses equipped with Image Stabilization
Always on
Only for shot
Video IS
A narrower angle of
view is used when digital image stabilization is selected in the menu. This is
equivalent to approx. 1.1x longer focal length when Electronic Image
Stabilization mode (Standard) is selected. Also, this is equivalent to approx.
1.43x longer focal length when Electronic Image Stabilization mode (High) is
selected
E-TTL balance
Ambience priority,
standard, flash priority
Compatible E-TTL Speedlites
Canon EX- and
EL-series Speedlites
E-TTL II Flash Metering
Evaluative (Face
Priority)
Evaluative
Average
Slow Sync (P/Av modes)
1/250 - 30 sec.,
auto
1/250 - 1/60 sec., auto
1/250 sec. (fixed)
Flash Function Menu
Provided for EX-
and EL-series Speedlites
Flash Exposure Compensation
+/-3 stops in 1/3-
or 1/2-stop increments
Continuous flash control
1. E-TTL each shot
2. E-TTL 1st shot
HDR PQ Shooting
Disable / Enable
HDR PQ Shooting - Still
Recording format:
HEIF
Bit depth: 10 bit
HDR specification: ITU-R BT.2100 (PQ)
Focusing
Dual Pixel CMOS AF
Exposure Compensation
+/-3 stops in 1/3-
or 1/2-stop increments
Canon Log
Provided (Off /
Canon Log 3)
Type
TFT color, liquid-crystal monitor
Monitor Size
3.2" (screen
aspect ratio of 3:2)
3.15" (8.01cm0 diagonal (2.63" (6.67cm) width, 1.75" (4.44cm)
height)
Dots
Approx. 2.1 million
dots
Coverage
Approx. 100%
vertically/horizontally
Brightness Control
Manually adjustable
to one of seven brightness levels
Coating
Clear View LCD II:
Anti-smudge coating applied
Anti-reflection coating not applied
Interface Languages
29 (English,
German, French, Dutch, Danish, Portuguese, Finnish, Italian, Ukraine,
Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian,
Vietnamese, Hindi, Romanian, Turkish, Arabic, Thai, Simplified/Traditional
Chinese, Korean, Malay, Indonesian, Japanese)
Highlight Alert
The white areas
with no image data will blink.
Histogram
Brightness and RGB
Function
The Quick Control
screen is accessed by pressing the Quick Control button during still photo
shooting
Image Protection
and Erase
Protection
Single image
(select image)
Select range
All images in a folder
All images on card
Image browsing and image search can be based on
ratings
Ratings-based image selections also possible with DPP
All found images (only during image search)
Erase
Except protected
images
(1) Select images to erase
(2) Select range
(3) All images in folder
(4) All images on card
(5) All fo)und
images (only during image search)
Compatible Printers
Not supported
DPOF: Digital Print
Order Format
DPOF
Compliant to DPOF
Version 1.1
Standards Compliance
IEEE
802.11a/ac/b/g/n
Transmission Method
DS-SS modulation
(IEEE 802.11b)
OFDM modulation (IEEE 802.11g/n/a/ac)
Transition Frequency (Central
Frequency)
2.4 GHz band:
Frequency: 2412 to 2462 MHz
Channels: 1 to 11 channels
5 GHz band:
Frequency: 5180 to 5825 MHz
Channels: 36 to 165 channels
Connection Method
Camera access point
mode
Infrastructure mode
Communication with a Smartphone
Images can be
viewed, controlled, and received using a smartphone.
Remote control of the camera using a smartphone is possible depending on the
Camera Connect specifications.
Images can be sent to a smartphone.
Remote Operation Using EOS Utility
The camera can be
controlled via Wi-Fi using EOS Utility
Print from Wi-Fi Printers
Not supported
Send Images to a Web Service
Still photos (RAW,
C-RAW, HEIF, and JPEG) and movies (MP4) can be uploaded to image.canon server album.
With the image.canon server, images can be sent to
social media or a photo album link can be sent (by the image.canon
specifications)
Standards Compliance
Bluetooth
Specification Version 5.0 compliant (Bluetooth low energy technology)
Transmission Method
GFSK modulation
Custom Functions
22 Custom Functions
are settable
Custom Controls
Customizable
Buttons:
Shutter button
Movie button
MODE button
AF-ON button
AE lock button
AF point button
Depth of field preview button
Lens AF stop button
Multi-function button
LCD panel illumination button
Set button
Multi-controller
Customizable Dials:
Main dial
Quick control dial 1 & 2
Control ring
My Menu Registration
Up to six top-tier
menu items and Custom Functions can be registered
Up to five My Menu tabs can be added
My Menu tab overall operations:
Adding a tab
Deleting tabs in a batch
Deleting all tab items
Setting the menu display
My Menu tab detailed operations:
Selecting a registered item
Sorting registered items
Deleting selected registered items
My Menu Registration (Contd.)
Deleting registered
items in a batch
Deleting tabs
Changing a tab name (16 ASCII characters)
USB Terminal
Equivalent to
Hi-Speed USB (USB 3.1 Gen 2)
For PC communication
Terminal type: USB Type-C
Shared with terminal for in-camera charging with USB Power Adapter PD-E1
In-camera Charging: Equivalent to USB type-C (5 V/1.5 A), but use should be
restricted to USB Power Adapter PD-E1
Video Output (UVC)
Canon App(s) for iPhone
PTP connection/GP-E2
Video Out Terminal
HDMI micro OUT
terminal Type D (Resolution switches automatically) / CEC not compatible
Images can be displayed through the HDMI output and on screen at the same time
Images will not be displayed unless (NTSC) or (PAL) is properly set according
to the video system of the TV set
Clean HDMI output
Provided
Microphone input terminal
3.5mm diameter
stereo mini jack
Headphone terminal
3.5mm diameter
stereo mini jack
Battery
LP-E6NH/LP-E6N/LP-E6
With the AC Adapter AC-E6N + DC Coupler DR-E6, AC power is possible
With the USB Power Adapter PD-E1, in-camera charging of LP-E6NH is possible.
The USB Power Adapter PD-E1 is not compatible with powering the camera
Battery Check
Automatic battery
check when the power switch is turned ON.
Displayed in 6 levels on top LCD panel
Battery level can be checked on the LCD panel and in the viewfinder
Battery Info display in Set-up Menu:
Type of power source used
Remaining capacity (percentage of battery charge remaining)
Recharge performance: (3-level display of battery's ability to hold a charge)
Start-up Time
Approx. 0.4 sec
Based on CIPA testing standards
Battery Info
Required, included
Battery Material
Lithium-ion
Battery Type
-
Battery Quantity
1
Working Temperature Range
32-104 Degree F
(0-+40 Degree C)
Working Humidity
Range 85% or less
Dimensions (W x H x D)
Approx. 5.6 x 4.0 x
4.4" (142 x 101 x 111mm)
Weight
Approx. 1.7 lbs (770g)
(Including Battery, CFexpress Card; Without Body Cap)
Approx. 1.5 lbs (680g) (Body Only)
